HOME / Product information / Take up winder EKTL-29D-350 (EKTL Series)
EKTL is mainly used for large package winding including precursor of PAN carbon fiber and also heavy industrial yarn. Many models are available depending on package size.
| Type | EKTL-29D-350 |
| Yarn type | thick denier filament etc |
| Number of filaments | 1000-30000 Denier (3000-48000) |
| Unrolling speed | Max.450m/min |
| Winding package shape | square end cheese roller (0-00') |
| Winding bobbin | Typepaper cone |
| SIZE133φ( ID ) / 10mm( length) | |
| Traverse length | 29inch(737mm) |
| Winding package | Max.900mmφ |
| Winding weight | Max.360kg |
| Unwinding tension | early tension0.94-19.6N(300-2000gf) than shorter |
| control devicedancer roller tension system, PID control device | |
| Pressure | 39.2-117.6N(4000-12000gf) than shorter |
| Drive system | geared motor : 3.7kW Individual drive |
| Machine construction | 1 bobbin(one machine) |
| Air pressure | 0.5-0.6MPa(5-6kgf/cm2) |
| Electrical device | 3 phase,200/220V, 50/60HZ |
| * Step-down Toransformer will be reguired when using the machines at the aria of Different power supply. |
|
